Plan LED step lighting.
Select the right system.
Prepare the technical integration.
For theatres, cinemas, auditoriums and performance venues: compare construction types, plan 24 V supply and cabling, coordinate DMX/DALI and prepare the information needed for the next project stage.
A finished specification is not required. Drawings, photographs or approximate dimensions are enough for an initial technical discussion.
Where are you in the project?
What do you need to clarify next?
Whether you have an early concept, a detailed technical question or a project ready for specification, start with the decision that is currently open.
Working with an existing installation? Start by identifying which steps, profiles, cable routes and control components can reasonably remain. Plan a refurbishment →
System selection & technical planning
First choose the construction. Then engineer the complete system.
The architecture determines how the light can be integrated. Electrical design then determines how the selected luminaires are supplied, dimmed and controlled.
Select the lighting approach
Start with the step geometry, floor finish, architectural appearance and intended light effect.
- Illuminated stair-nosing and step profiles
- Flush recessed light lines
- Stage and platform edge lighting
- Fixed or portable construction
Engineer power, control and interfaces
Once the luminaire concept is clear, the electrical and installation conditions need to be coordinated with the project team.
- 24 V supply, circuits and cable routes
- Cable length and voltage drop
- DMX, DALI and low-level dimming
- Backup operation and local responsibilities
Technical planning topics
Installation, electrical design and project requirements.
These are the questions that typically need to be resolved before lengths, circuits and the final system configuration can be released.
24 V planning
Cable length, load and circuit structure belong together.
A 24 V lighting system should not be planned from luminaire quantity alone. The electrical path from the power supply to the last light line matters.
Consider the complete circuit.
For preliminary planning, record the connected LED load, cable length, conductor size and intended feed points. Long cable runs or high loads may require additional feeds or a different circuit allocation.
- LED power per circuit
- One-way cable length
- Conductor cross-section
- Permissible voltage drop
Define circuits before the installation is closed.
Power supplies, dimmers and distribution points should remain accessible. Separate aisles, seating blocks or lighting functions where this supports operation, commissioning or later maintenance.
- Accessible power and control equipment
- Clearly assigned lighting zones
- Labelled circuits and connection points
- Reserve for future extensions where required
Project requirements
Step lighting, backup operation and safety lighting are not automatically the same thing.
The intended function needs to be defined within the overall project concept before supply, monitoring and testing requirements can be determined.
Normal step-lighting operation
Step lighting can provide visual orientation and mark changes in level during normal venue operation. Brightness, dimming and control are coordinated with the use of the room.
Requirements must be defined by the responsible planning team.
If the lighting is intended to form part of statutory emergency or safety lighting, applicable local requirements for supply, monitoring, runtime, cable systems, testing and documentation must be established by the responsible electrical and life-safety planning.
Prepare the project information
Structure the data before the final system is defined.
The following planning tasks mirror the information normally needed for technical coordination, quotation and later fabrication.
These steps support preliminary planning. Final power, controls, installation details and local compliance remain project-specific.
Drawings, technical data & project evidence
Use the information needed for the current planning stage.
Product drawings & datasheets
Compare the mechanical geometry of SL1, SL2, SLR, SLD and BL and open the corresponding technical datasheets.
Open drawings & datasheetsControls & electrical integration
Review power supplies, dimming, DMX/DALI, control cabinets and project-specific battery systems.
Open control-system informationRealised projects
Explore documented installations in theatres, cinemas, auditoriums, venues and movable seating structures.
View project referencesTechnical project coordination
You do not need to have specified the technology yet.
Describe the room, step construction or open technical question. We will structure the information, identify missing details and define the next planning step with you.
Drawings, photographs, sections or approximate dimensions can be included where already available.
